Stainless Steel Wall Mounted Jib Crane

The stainless steel wall mounted jib crane is a lightweight lifting device installed on a wall or column structure. It enables efficient material handling within a limited working radius through the rotation of its jib arm. This type of jib crane does not occupy floor space and allows precise lifting operations at local workstations, making it ideal for compact production environments with high cleanliness requirements.

Compared with traditional carbon steel jib cranes, its advantages are:

• Smooth surface, low dust adhesion and easy cleaning

• Excellent resistance to acids, alkalis and corrosion

• Suitable for high cleanliness environments (ISO Class 5 - 8)

Main Components of Stainless Steel Wall Mounted Jib Crane

Stainless steel wall support structure: Fixed to walls or steel structures using high strength bolts or chemical anchors, with no floor space occupied.

High strength jib beam: The jib arm is designed with a box-type or I-beam structure, allowing up to 180° horizontal rotation.

Slewing mechanism: Equipped with bearing slewing system or thrust bearing assembly, ensuring smooth operation, low resistance and precise positioning.

Lifting mechanism: Can be matched with cleanroom electric chain hoists or stainless steel manual chain hoists for stable lifting.

Product Advantages of Stainless Steel Jib Crane

• The whole crane is made of 304 or 316 stainless steel, preventing rust and dust pollution, ideal for semiconductor, pharmaceutical and food industries.

• The wall mounted design eliminates the need for floor columns, improving workspace layout and increasing space utilization.

• The jib arm rotates freely within a defined working radius, working together with the lifting hoist to enable efficient material transfer.

• Supports customized design: load capacity, jib length, rotation angle, material and lifting device can be customized according to production requirements.

Material Handling Solutions for Various Cleanroom Applications

Semiconductor & electronics manufacturing: Used for wafer handling, equipment maintenance and precision component assembly.

Food production workshops: Used for raw material handling, equipment servicing, and packaging line material transfer.

Pharmaceutical industry: Suitable for GMP cleanrooms for raw material transfer, reactor maintenance and auxiliary lifting in packaging lines.

Technical Parameters (Customizable)

• Rated load: 100 kg - 2000 kg

• Jib length: 2 m - 6 m

• Rotation angle: 90° / 180° / 270°

• Material: 304 / 316L stainless steel

• Lifting mechanism: stainless steel manual chain hoist / cleanroom electric chain hoist

• Installation type: wall mounted / steel structure support

Industrial Safety Design

• Equipped with travel limit devices to prevent over-rotation

• Overload protection system included

• High strength fastening at critical connection points

• Wear resistant slewing bearings to reduce failure rate

If you are looking for a stainless steel jib crane for your cleanroom workshop, contact our engineering team today for professional customized solution and product quotation.
